LED P160 Indoor display screen

Technical Parameters

Item No.: GS-N160-in

Name: LED P160 Indoor display screen

Wight:2.1kg/unit

Size of standard unit: 160*160mm

SPECIFICATIONS

Pixel pitch: 16 mm

pixel density: 3906Dots/m2

Pixel configuration: 1R1G1B

Led stand:  SMD0805

Moudel resolution:16*16Dots

Cabinet resolution: 256mm X128mm

Cabinet size:1024 x768 x 120mm

Cabinet weight:30kg

Brightness:>  >300cd/m²

Optimal visual distance: >15m

Luminance material:   USA chips

Average power consumption: ≤0.4KW/m²

Horizontal >140º  Vertical >140º MTBF:>10000

Gray grade level: Point-by-point 4096 gray grade levels for

                each color, γ correction is available.

Gray grade correction: 32-level nonlinear gray grade correction

Control method: 1/8 dynamic scan

Protection level:IP31

Description

Brightness adjustment: Software allows continuous adjustment

                      from 0% to 100% according to environmental brightness.

Drive method:         Constant current driving

Input signal:         Video、S-video signal，RGB digital signal, etc.

Working voltage:     AC220V+/-10%, 50Hz, or AC110V+/-10%,60Hz

Working temperature:  -20 ºC  ~  +50ºC

Storage temperature:   -30 ºC  ~  +90ºC

Ambient relative humidity:  25% ~ 95% RH

Communication distance: Network cable: 120m, multi mode fibre

                        cable: 500m, single mode fibre

                        cable: 15km

Screen life:             50,000 hours
