300W moving head beam light

 Name :300W moving head beam light

Item No.: GS-300

Size: L378×W396×H631mm

N.W: 18 kgs

Specifications

Lamp: Jenbo, Power consumption:500W

.Channel:12 CHS

1 color wheel+1 gobo wheel+gobo shake

Light source,  Jenbo

eletronic ballast(traditonal)

210/230/245v/50hz

208/230v/60hz

eletronic ballast

100/120/210/230/250v 50/60HZ

Power consumption:500W

Control,  controller switch the bulbs or manual use, lamp automatically off after 15 miniunts when there is no sign to input. You can use controller to change the color wheel to be half-color, full colors or slide.

Main color wheel, 8main color+1white color, adpot color temperature 2500k and 3200k chips.

Gobo Wheel 1, 8colors+1white color fixed gobos,with indexable and bi-directionally rotation, gobo shake function.

Atomizer: atomizer function with adjustable speeding.

Dimmer, one dimmer channel, 0-100% linear electroic dimmer.

Pan/Tilt movement range,  Pan 540degree    Tilt: 280degree

X/Y axis 8/16bis, ajustable axis speeding and intelligent error-correcting memory function

Control& Programs

LED Display, adjustable(10-100%) backgroud color or close backgroud color, it can be recover by press any keys.

Control mode. DMX512 or WDMX

Control CH: 12CHS

Singal input/output: 3pins or 5 pincs XLR Socket

Singal connection: Pin 1(earth) Pin2(Female) Pin3(Male)
