RGB Laser lights

Name: RGB Laser lights

Item No.: GS-L01

Packing Size: 800×430×180 mm

Net Weight: 24kg

Flight Case Size: 830×460×250 mm

Gross Weight: 39Kg (Standard flight case package)

Electrical

l  Voltage: 85-260V AC(Automatic adjustment)

l  Frequency: 50~60Hz

l  Optical Angle:+/-30°

l  Scan System : ILDA 30Kpps~ILDA 40Kpps

Laser Diode

Diode Laser/ Diode Pumped

Solid State Laser(DPSS).Total Laser Power:

1000mw(Sectable Power:1000mw-3000mw)

Laser Class:4

l  Green(532nm)>400mw

Red(635nm)>200mw (Optional Wavelength:650nm)

Bule(450nm)>400mw

Working mode

Sound Acive/Auto-Play/Master- Slave/DMX512/PC (ILDA standard connector)

l  Dmx,music active&automatic

l  Pc  laser show software:Pangolin,phoenix,ishow and extc(via ilda port)

 [FEATUES]

l  RGB full color animation laser with high-speed optical scanner to create Beam show ,

Animation Show and Text show

l  Support lasershow software. e.g Pangolin , Phoenix,Mamba

l  Auto switch between internal program and PC

l  One or 16 units work synchronously under the control of computer

l  Safety Capacity: Design according to security and good performance, safer to human and environment.

l  Auto close light when scanner have trouble

l  Applicable for Disco, clubs, KTV, pub, bar, family party etc
